Features
Thick heavy industrial chassis | Pump water shortage protection system |
Dustproof and waterproof shell design | High pressure solenoid valve automatic pressure relief |
Thickened stainless steel water tank 80L | Motor thermal overload protection |
Large flow inlet float valve | Built-in two sets of precision filters |
Technical Parameters
model | DZJCZ-8F | DZJCZ-12F | DZJCZ-18F |
Motor and power | ABB motor 1.1kw | ABB motor 2.2kw | ABB motor 3.3kw |
Display | Siemens touch screen | Siemens touch screen | Siemens touch screen |
Control System | Mitsubishi PLC automatic control system | Mitsubishi PLC automatic control system | Mitsubishi PLC automatic control system |
Line control | Dual line control | Dual line control | Dual line control |
Number of nozzles | 100Pc | 160Pc | 240Pc |
size | 75*63*103 (cm) | 75*63*103 (cm) | 75*63*103 (cm) |
Working pressure | 4-7Mpa (40-70kg) Adjustable | 4-7Mpa (40-70kg) Adjustable | 4-7Mpa (40-70kg) Adjustable |
Maximum flow | 8(L/min) | 12(L/min) | 18(L/min) |
Voltage | 380V | 380V | 380V |
Test pressure 10Mpa (100kg)
Inlet pressure "2.0kg water supply flow rate is not less than 1.5 cubic meters / hour
Input power AC380V/150Hz or AC220V/50Hz
Net weight 112kg
Motor speed 1450 (r/min)
